Description
Features
- MIG DC, Single & Double Pulse: 250A @ 18%
- Stick and Stick with Pulse: 205A @ 25%
- 4x Feed Roll Geared Wire Drive System
- Plate Thickness Control with Joint Type Selection (Quickset)
- 60x Memory provisions
- PFC
- IP23S
- 3 Year Warranty
Specifications
- Single Phase – 15A Plug230V +/- 10%
- AS 60974.1:2020
- 50/60Hz
- Minimum Generator Supply: 10.5 kVA (0.8 Power Factor at Max Amps)
- Amperage Range: MIG: 30A – 250A TIG: 10A – 250A STICK: 30A – 205A
- MIG Duty Cycle @40% : 250A @ 18%, 26.5V
- TIG Duty Cycle at 40%: 250A @ 25%, 20.0V
- Stick Duty Cycle @ 40% : 205A @ 25%, 28.2V
- VRD in Stick Mode
- Protection Class: IP23S
- Country of Origin: China
- Warranty: 36 – Months
Inclusions
- 3m NEXARC BZ26 MIG Gun with 4-Button Control
- 200A Twist lock Electrode Holder with 3m Lead
- 2m Quick Connect Gas Hose
- 300A Earth Clamp with 3m Lead
- BlueJet Regulator/Flowmeter
- Mild Steel Liner (Fitted), Nylon Liner, Inlet/Outlet Guides
- Feedrolls: 0.8/0.9mm (x2) V-Groove (Fitted), 0.8/0.9mm (x2) Knurled, 1.0/1.2mm (x2) U-Groove
- Operating Manual
