Description
The Copeland 040532 (Model 222CB1-1/4B1-1/4T) is a heavy-duty, 2-way normally closed industrial solenoid valve engineered for demanding steam and fluid control applications. Built with a robust brass valve body and rated for steam service up to 150 PSI, this valve delivers reliable shutoff performance in commercial and industrial HVAC, process, and utility systems.
With a generous 16.0 Cv flow coefficient and a 1-1/4″ NPT connection on both inlet and outlet, this valve is well-suited for high-flow applications where precise on/off control is required. The normally closed design ensures the valve defaults to the closed (safe) position whenever the coil is de-energized, making it ideal for fail-safe system designs.
Key Features
- 2-way, normally closed (NC) operation — closes when de-energized for fail-safe control
- 1-1/4″ NPT inlet and outlet connections for easy installation into standard piping
- 16.0 Cv flow coefficient for high-capacity fluid and steam flow
- Industrial brass valve body for durability and corrosion resistance
- Rated for steam service: 0–150 PSI operating pressure range
- Suitable for steam, water, and compatible fluid media in industrial environments
Specifications
- SKU / Part Number: 040532
- Model Number: 222CB1-1/4B1-1/4T
- Valve Type: 2-Way Solenoid Valve, Normally Closed
- Connection Size: 1-1/4″ NPT (inlet and outlet)
- Cv Flow Coefficient: 16.0
- Valve Body Material: Brass
- Pressure Rating: 0–150 PSI (Steam)
- Media: Steam and compatible fluids
- Brand: Copeland
Applications
- Commercial and industrial steam distribution systems
- HVAC heating coil control
- Process fluid on/off control
- Boiler and steam plant ancillary control
- Industrial automation and utility systems
