Description
Details
- Center hole: 3/4″
- Requires 1, 91-723 blade and 1, 91-701 blade for 38″ cut
- Enhanced mulching for bagging and discharge efficiency
- Stays sharp and durable for longer
- Fits Massey Ferguson model: 2521, 25195
Blades
| Blade WidthMeasure near the center of the blade. | 2.00″ |
| Blade ThicknessMeasure near the center of the blade. | 0.203″ |
| Blade LengthMeasured diagonally from the corners of the blade | 16-1/8″ |
| Outer Hole DiameterThis is the diameter of any holes to the sides of the center hole. | 3/8″ |
| Center Hole SizeMany blades will have a round hole in the center of the blade and you will need to know its diameter. Blade Length 5 or 7 Point Star Center holes may be 5 or 7 point star shaped. 5 point star on blade7 point star on blade Square or Rectangular The MTD built blades on many walk behind lawn mowers have a ‘bow-tie’ hole. In this case the Oregon replacement blade will have a rectangular center hole which will fit on the bow-tie pattern on the blade adapter. Square or Rectangular hole on blade MTD Blades The MTD® built blades (Bolens, Cub Cadet, Troy-bilt, White, Yard Machine, and Yardman) may have a 6 point star. Oregon replacement blades will have a ‘Y’ shaped center hole which will fit exactly on the 6 point star on the blade spindle. 6 point star for MTD blades The two sizes of the 6 point star. If your blade spindle has a bolt and lock washer that holds the blade to the machine you would use the 11/16″ star or ‘Y’ blade. blade spindle with bolt and lock washer. If your blade is secured with a large flange nut then you would use the 5/8″ star or ‘Y’ blade. blade spindle with large flange nut | 3/4″ |
| Center-to-CenterIf there are outer holes; this is the distance between the centers of those outer holes. | 2-9/16″ |
| OffSet(Sometimes referred to as offset): If you set the blade on a table this is the distance the center of the blade is above the table top (if any) when the cutting edges are flat on the table | 0 |
| Air LiftAir lift is the distance the lift panel rises above the cutting edge. | 1-1/8″ |
General
| Color | Black |
| Volume | 348.219 in3 |
| Product UOM | Each |
| Weight (with Packaging) | 1.75 Lb |
| Product Height | 0.203 |
| Product Length | 16-1/8″ |
| Product Width | 2 |
| Packaged Length | 22.7″ |
| Packaged Width | 5.9″ |
| Packaged Height | 2.6″ |
Click these tabs for additional compatibility information.
- Replaces
- Compatible Models
Replaces
Massey Ferguson:
1704100, 1704856ASM
Rotary:
10095
Simplicity:
17027774, 17027774SM, 1704100, 1704100A, 1704100ASM, 1704100BMA, 1704100BZ, 1704100SM, 1704856, 1704856A, 1704856ASM, 1704856BMA, 1704856BZ, 1704856SM, 1716696, 1716696A, 1716696ASM, 1716696SM, 1727774, 1727774A, 1727774ASM, 1727774BMA, 1727774BZ, 1727774SM, 71704100, 71704100A, 71704856
Snapper:
17027774, 1704100, 1704100A, 1704100BMA, 1704100BZ, 1704856, 1704856A, 1704856ASM, 1704856BMA, 1704856BZ, 1716696, 1716696A, 1716696ASM, 1716696SM, 1727774, 1727774A, 1727774BMA, 1727774BZ
Stens:
345-106
Sunbelt:
B1SP2902
