Description
Features:
- Silicon Carbide Technology
- Dual Plug Compatibility (10A & 15A)
- Smart Fan
- 5” Colour LCD Touchscreen
- Power Factor Correction (PFC)
- Job Memory
- 5” Colour LCD Touchscreen
- Generator Compatible
- IP21S Rating
- Foot Control Ready
Technical Specifications:
- Technical Data:SKU: U11024 Primary Input Voltage: 240V Single Phase 50/60Hz Supply Plug: 10/15A Ieff (A): 9.7A (10A) / 14.8A (15A) Imax (A): 29.3A Rated Output: 2-230A No Load Voltage (V): 100V Protection Class: H Insulation Class: IP21S Minimum Generator (kVA): 8 Dinse Connector: 35/50 Standard: AS 60974.1 Welds: TIG: Aluminium, Magnesium, Zinc Alloys, Mild Steel, Stainless Steel, Copper, Silicon Bronze, Titanium mmA: Mild Steel, Stainless Steel, Cast Iron:Warranty (Years): 3 TIG Specifications:TIG Function Type: AC/DC HF TIG & AC/DC Pulse TIG Welding Current Range: 2-230A TIG Duty Cycle @ 40°C: 15% @ 230A, 60% @ 115A, 100% @ 89A (10A):35% @ 230A, 60% @ 176A,:100% @ 136A (15A):TIG Welding Thickness Range: 1-12mm mmA Specifications:STICK Welding Current Range: 10-200A STICK Duty Cycle @ 40°C: 10% @ 200A, 60% @ 82A, 100% @ 63A (10A):20% @ 200A, 60% @ 115A,:100% @ 90A (15A):STICK Electrode Range: 2.5-4.0mm STICK Welding Thickness Range: 2-12mm Size & Weight:Dimensions (mm): 680x210x395mm Weight (kg): 20.6kg
Inclusions:
- ENVY TIG 230 AC/DC Welder 8m T2 TIG Torch 4m Twist Lock Electrode HOLD – Loadeder 4m 300 Amp Earth Clamp & Lead Argon Flowmeter Regulator 1.8m Gas Hose with fittings 15A to 10A Conversion Lead Operating Manual
